2400H Super Q Piston Vacuum Pump, 0.9kW 210L/min -98kPa Oil-Free
The 2400H Super Q piston vacuum pump is a high-performance, oil-free reciprocating pump designed for laboratory and precision vacuum applications.
- 210 L/min Flow Rate
- -98 kPa Max Continuous Pressure
- 0.9 kW Power Rating
Need help applying this product? Our engineers can help select the right equipment and design a system around your requirements. Request a quote or discuss your application with us.
Need help choosing? Send us the part number or your operating data — talk to an engineer or see full specifications.
- Fast dispatchAustralia & worldwide
- Technical supportTalk to an engineer
- 12 MonthsWarranty
Product Overview
The 2400H Super Q piston vacuum pump is a high-performance, oil-free reciprocating pump designed for laboratory and precision vacuum applications. Engineered for low-noise operation and high efficiency, it delivers clean vacuum without oil contamination.
With a maximum flow rate of 210 L/min and vacuum level up to -98 kPa, this pump is ideal for controlled vacuum environments requiring reliability and stable performance.
Technical Specifications
| Specification | Value |
|---|---|
| Product Name | Piston Vacuum Pump |
| Model | 2400H |
| Brand | Super Q |
| Pump Type | Piston Pump |
| Structure | Reciprocating |
| Pressure | High Vacuum |
| Max Continuous Pressure | -98 kPa |
| Flow Rate | 210 L/min |
| Speed | 1450 / 1740 RPM |
| Motor Type | Electric Motor (100% Copper) |
| Power Source | Electric |
| Power Rating | 0.9 kW |
| Voltage | AC 220V / 380V |
| Pump Body Material | Industrial Alloy |
| Sealing Type | Oil-Free |
| Noise Level | Low Noise Design |
| Suitable Media | Air |
| Application Scope | Laboratory / Industrial |
| Dimensions | Compact design |
| Warranty | 12 Months |
Key Features
- Oil-free piston vacuum technology
- Vacuum up to -98 kPa
- Flow rate up to 210 L/min
- Low noise operation
- High efficiency copper motor
- Suitable for continuous-duty operation
Typical Applications
- Laboratory vacuum systems
- Analytical equipment
- Industrial testing systems
- Air evacuation systems
- Research and development
- Precision vacuum environments
Shipping & Support
- Fast dispatch - Australia & World wide shipping
- Technical assistance available
- 12-month warranty
