A4VG40 Rexroth Axial Piston Hydraulic Pump, 40cc, Flange Mount, Right Rotation
The A4VG40 axial piston hydraulic pump is part of the Rexroth A4VG series designed for closed-loop hydrostatic drive systems.
- 40 cc Displacement
- Right-hand (Clockwise from shaft end) Rotation
Need help applying this product? Our engineers can help select the right equipment and design a system around your requirements. Request a quote or discuss your application with us.
Need help choosing? Send us the part number or your operating data — talk to an engineer or see full specifications.
- Fast dispatchAustralia & worldwide
- Technical supportTalk to an engineer
- 12 MonthsWarranty
Product Overview
The A4VG40 axial piston hydraulic pump is part of the Rexroth A4VG series designed for closed-loop hydrostatic drive systems. This variable displacement pump delivers efficient hydraulic power transmission and precise flow regulation in demanding mechanical environments.
Constructed with high-precision piston components and a robust cast housing, the pump ensures reliable performance and long service life. It is commonly installed in construction equipment, hydraulic drive systems, and industrial machinery.
Technical Specifications
| Specification | Value |
|---|---|
| Product Name | Axial Piston Hydraulic Pump |
| Model | A4VG40 |
| Series | A4VG |
| Pump Type | Variable Displacement Piston Pump |
| Displacement | 40 cc |
| Hydraulic Circuit | Closed Loop |
| Rotation | Right-hand (Clockwise from shaft end) |
| Mounting Type | Flange Mount |
| Pressure Type | High Pressure |
| Housing Material | Cast Iron |
| Condition | New |
| Warranty | 12 Months |
Key Features
• Variable displacement piston pump design
• Efficient hydrostatic drive operation
• Durable cast iron pump housing
• Stable pressure regulation performance
• Reliable heavy machinery performance
• Long service life
Typical Applications
• Construction equipment
• Hydraulic excavators
• Mining machinery
• Industrial hydraulic systems
• Agricultural machinery
Shipping & Support
• Fast dispatch – Australia & world-wide shipping
• Technical assistance available
• 12-month warranty
