BZ100E-50 Yangzijiang High-Pressure Self-Priming Centrifugal Pump, 5HP DN150
The BZ100E-50 Yangzijiang self-priming centrifugal pump is designed for high-pressure sewage, slurry, and mining fluid transfer applications.
- 120 – 300 m³/h Flow Rate
- 3.6 MPa Max Continuous Pressure
- 27 – 102 m Head
Need help applying this product? Our engineers can help select the right equipment and design a system around your requirements. Request a quote or discuss your application with us.
Need help choosing? Send us the part number or your operating data — talk to an engineer or see full specifications.
- Fast dispatchAustralia & worldwide
- Technical supportTalk to an engineer
- 12 MonthsWarranty
Product Overview
The BZ100E-50 Yangzijiang self-priming centrifugal pump is designed for high-pressure sewage, slurry, and mining fluid transfer applications. Built with a high chromium alloy impeller and robust construction, it delivers reliable performance in beneficiation and abrasive environments.
With a flow capacity of 120–300 m³/h and pressure up to 3.6 MPa, this pump ensures efficient handling of solids and high-demand industrial fluids while maintaining stable operation under continuous duty.
Technical Specifications
| Specification | Value |
|---|---|
| Product Name | Self-Priming Centrifugal Pump |
| Model | BZ100E-50 |
| Brand | Yangzijiang |
| Pump Type | Centrifugal Pump |
| Structure | Horizontal Self-Priming |
| Pressure | High Pressure |
| Max Continuous Pressure | 3.6 MPa |
| Flow Rate | 120 – 300 m³/h |
| Head | 27 – 102 m |
| Suction Head | 4.8 m |
| NPSHr | 4.8 m |
| Speed | 1480 r/min |
| Motor Type | Electric Motor |
| Power Source | Electric |
| Power Rating | 5 HP |
| Max Motor Power | 200 kW |
| Voltage | 380V |
| Impeller Material | High Chromium Alloy |
| Pump Body Material | Industrial Alloy |
| Inlet Size | DN150 |
| Outlet Size | DN150 |
| Discharge Particle Size | Up to 42 mm |
| Inlet Height | 500 – 1200 mm |
| Connection Type | Shaft Coupling |
| Control Method | Fully Automatic |
| Surface Treatment | Spraying |
| Applicable Temperature | 5 – 80°C |
| Weight | 1200 kg |
| Warranty | 12 Months |
Key Features
- High-pressure performance up to 3.6 MPa
- Self-priming capability for efficient startup
- High chromium alloy impeller for abrasion resistance
- Handles solids up to 42 mm
- Large flow capacity up to 300 m³/h
- Designed for mining and beneficiation applications
Typical Applications
- Mining operations
- Beneficiation processes
- Slurry and sewage transfer
- Industrial wastewater systems
- Sand and gravel handling
- Pumping stations
Shipping & Support
- Fast dispatch - Australia & World wide shipping
- Technical assistance available
- 12-month warranty
