Fisher FIELDVUE DVC6200 SIS Explosion-Proof Digital Valve Controller
The Fisher FIELDVUE DVC6200 SIS Explosion-Proof Digital Valve Controller is an intelligent electro-pneumatic instrument designed for accurate pneumatic valve control and safety shutdown applications in industrial process systems. Manufactured by Fisher, an...
- Actuator Mounted or Remote Mounted Mounting Configuration
- 10 bar / 145 psig Maximum Supply Pressure
Need help applying this product? Our engineers can help select the right equipment and design a system around your requirements. Request a quote or discuss your application with us.
Need help choosing? Send us the part number or your operating data — talk to an engineer or see full specifications.
- Fast dispatchAustralia & worldwide
- Technical supportTalk to an engineer
- 1 YearWarranty
Product Overview
The Fisher FIELDVUE DVC6200 SIS Explosion-Proof Digital Valve Controller is an intelligent electro-pneumatic instrument designed for accurate pneumatic valve control and safety shutdown applications in industrial process systems. Manufactured by Fisher, an Emerson brand, this digital valve controller uses HART communication technology to monitor valve performance, regulate pneumatic actuator movement, and support Safety Instrumented Systems (SIS). Its advanced diagnostic capabilities enable reliable valve positioning, partial stroke testing, and continuous monitoring of critical safety valves.
The DVC6200 SIS features contactless magnetic position feedback, microprocessor-based control, configurable pneumatic outputs, and a durable industrial enclosure with explosion-proof configurations. Its modular construction supports installation on compatible linear and rotary actuators, including suitable Wuzhong valve assemblies. It is suitable for water treatment, oil and gas processing, chemical manufacturing, power generation, and industrial process automation.
Technical Specifications
|
Specification |
Value |
|---|---|
|
Product Name |
Explosion-Proof Digital Valve Controller |
|
Manufacturer / Brand |
Emerson / Fisher |
|
Model Number |
DVC6200 SIS |
|
Product Series |
FIELDVUE DVC6200 |
|
Product Type |
Intelligent Electro-Pneumatic Valve Controller |
|
Instrument Technology |
Microprocessor-Based Digital Control |
|
Primary Function |
Pneumatic Valve Control and Safety Shutdown |
|
Safety Application |
Safety Instrumented Systems (SIS) |
|
Communication Protocol |
HART 5 or HART 7 |
|
Analog Input Signal |
4–20 mA DC |
|
Pneumatic Output |
Up to Full Supply Pressure |
|
Maximum Supply Pressure |
10 bar / 145 psig |
|
Pneumatic Action |
Single Acting or Double Acting, Depending on Configuration |
|
Position Feedback Technology |
Contactless Magnetic Hall-Effect Sensor |
|
Diagnostic Functions |
Valve Monitoring and Partial Stroke Testing |
|
Safety Capability |
SIL 3 Capable in Approved Applications |
|
Hazardous Area Protection |
Explosion-Proof and Flameproof Configurations Available |
|
Enclosure Protection |
IP66 / Type 4X |
|
Housing Material |
Aluminium Alloy or Stainless Steel |
|
Supply Medium |
Clean, Dry Air or Natural Gas |
|
Operating Temperature |
−52°C to +85°C, Subject to Configuration |
|
Electrical Connection |
1/2 NPT or M20 |
|
Pneumatic Connection |
1/4 NPT, Standard Low-Bleed Configuration |
|
Actuator Compatibility |
Linear and Rotary Pneumatic Actuators |
|
Valve Compatibility |
Fisher and Compatible Wuzhong Valve Assemblies |
|
Mounting Configuration |
Actuator Mounted or Remote Mounted |
|
Configuration Software |
Fisher ValveLink |
|
Control Functions |
On/Off, Modulating and Safety Shutdown |
|
Operating Application |
Industrial Valve Automation and Safety Control |
|
Condition |
New |
|
Warranty |
1 Year |
Key Features
Intelligent electro-pneumatic valve control
Explosion-proof construction options for hazardous environments
Integrated HART digital communication technology
Accurate 4–20 mA electrical control signal
Contactless magnetic valve position feedback
Advanced partial stroke testing functionality
Continuous valve performance and condition monitoring
Safety Instrumented System integration
SIL 3 capable design for approved safety applications
Durable IP66-rated industrial enclosure
Configurable single-acting and double-acting pneumatic operation
Compatible with linear and rotary valve actuators
Modular construction for simplified servicing and maintenance
Supports compatible Fisher and Wuzhong valve installations
Reliable pneumatic valve control for industrial automation
Typical Applications
Industrial pneumatic control valve positioning
Safety Instrumented System valve applications
Emergency shutdown valve automation
Water and wastewater treatment facilities
Oil and gas production and processing plants
Chemical and petrochemical manufacturing facilities
Petroleum refining installations
Power generation and utility systems
Industrial pressure and flow control systems
Pneumatic actuator monitoring and diagnostics
Industrial safety valve partial stroke testing
Process automation and instrumentation systems
Shipping & Support
Fast dispatch – Australia & Worldwide Shipping
Technical assistance available
1-year warranty
