Fisher 2E669902202 Type 667 Pneumatic Actuator Diaphragm
The Fisher 2E669902202 Pneumatic Actuator Diaphragm is a replacement component designed for compatible Fisher Type 667 diaphragm actuators in industrial control valve systems.
- Spring-Return Diaphragm Actuator Actuator Configuration
- 34 and 40 Compatible Actuator Sizes
Need help applying this product? Our engineers can help select the right equipment and design a system around your requirements. Request a quote or discuss your application with us.
Need help choosing? Send us the part number or your operating data — talk to an engineer or see full specifications.
- Fast dispatchAustralia & worldwide
- Technical supportTalk to an engineer
- 1 Year Warranty
Product Overview
The Fisher 2E669902202 Pneumatic Actuator Diaphragm is a replacement component designed for compatible Fisher Type 667 diaphragm actuators in industrial control valve systems. Manufactured for Fisher equipment by Emerson, this molded nitrile and nylon diaphragm provides a flexible pressure-responsive barrier that converts pneumatic pressure into mechanical movement. Its construction supports effective pressure sealing, reliable actuator response, and consistent valve operation.
The 2E669902202 is specified for Fisher Type 667 actuators in sizes 34 and 40. It is used to replace worn, damaged, or leaking actuator diaphragms during equipment servicing. By helping maintain the separation between pneumatic pressure chambers and ensuring effective pressure transmission, the diaphragm supports reliable operation in oil and gas processing, chemical manufacturing, power generation, water treatment, and industrial automation.
Technical Specifications
|
Specification |
Value |
|---|---|
|
Product Name |
Pneumatic Actuator Diaphragm |
|
Manufacturer / Brand |
Fisher / Emerson |
|
Part Number |
2E669902202 |
|
Product Type |
Actuator Replacement Diaphragm |
|
Component Category |
Pneumatic Actuator Spare Parts |
|
Compatible Actuator |
Fisher Type 667 |
|
Compatible Actuator Sizes |
34 and 40 |
|
Diaphragm Material |
Molded Nitrile/Nylon |
|
Diaphragm Construction |
Reinforced Flexible Membrane |
|
Primary Function |
Pneumatic Pressure Sealing and Force Transmission |
|
Diaphragm Design |
Molded, Circular |
|
Nominal Outside Diameter |
13.25 Inches |
|
Nominal Centre Hole Diameter |
0.381 Inches |
|
Nominal Bolt Circle Diameter |
12 Inches |
|
Installation |
Internal Actuator Diaphragm Replacement |
|
Actuator Configuration |
Spring-Return Diaphragm Actuator |
|
Compatible Valve Systems |
Selected Fisher Sliding-Stem Control Valves |
|
Operating Medium |
Compatible Pneumatic Instrument Air |
|
Quantity |
1 Diaphragm |
|
Condition |
New |
|
Warranty |
1 Year |
Key Features
Replacement diaphragm for Fisher Type 667 pneumatic actuators
Original manufacturer part number 2E669902202
Compatible with Fisher actuator sizes 34 and 40
Molded nitrile and nylon construction
Flexible reinforced design for pneumatic pressure response
Supports effective sealing within actuator assemblies
Helps restore reliable actuator movement and positioning
Suitable for replacing worn or damaged diaphragms
Designed for compatible industrial control valve equipment
Supports preventive maintenance and actuator refurbishment
Useful for reducing pneumatic air leakage caused by diaphragm wear
Suitable for professional industrial valve maintenance
Typical Applications
Fisher Type 667 actuator maintenance
Pneumatic actuator diaphragm replacement
Industrial control valve servicing
Oil and gas processing facilities
Chemical and petrochemical manufacturing plants
Petroleum refining installations
Power generation and utility systems
Water and wastewater treatment facilities
Industrial pneumatic equipment refurbishment
Sliding-stem control valve actuator repair
