Flowserve PMV EP5XX-HPNU-39K01-PV9DA-4Z Electro pneumatic Valve Positioner
The Flowserve PMV EP5XX-HPNU-39K01-PV9DA-4Z Electropneumatic Valve Positioner is designed for precise positioning and automated control of pneumatic valve actuators in industrial process systems.
- Double Acting Actuator Configuration
- 1.4–10 Bar Supply Pressure Range
Need help applying this product? Our engineers can help select the right equipment and design a system around your requirements. Request a quote or discuss your application with us.
Need help choosing? Send us the part number or your operating data — talk to an engineer or see full specifications.
- Fast dispatchAustralia & worldwide
- Technical supportTalk to an engineer
- 1 Year Warranty
Product Overview
The Flowserve PMV EP5XX-HPNU-39K01-PV9DA-4Z Electropneumatic Valve Positioner is designed for precise positioning and automated control of pneumatic valve actuators in industrial process systems. Manufactured by PMV, a Flowserve brand, this positioner converts a standard 4–20 mA electrical input into proportional pneumatic control pressure. Its high-performance spool valve supports responsive actuator movement, stable positioning, and reliable industrial process control.
Part of the PMV EP5 Series, this model features a double-acting pneumatic configuration, high-performance spool, spindle configuration 39, and K01 cam. Its epoxy-coated aluminium housing incorporates a 90-degree direct-acting position indicator, 1/4-inch NPT pneumatic connections, and a 1/2-inch NPT electrical entry. The positioner is suitable for oil and gas processing, chemical manufacturing, power generation, water treatment, and industrial valve automation.
Technical Specifications
|
Specification |
Value |
|---|---|
|
Product Name |
Electropneumatic Valve Positioner |
|
Manufacturer / Brand |
PMV / Flowserve |
|
Model Number |
EP5XX-HPNU-39K01-PV9DA-4Z |
|
Product Series |
EP5 |
|
Product Type |
Analogue Electropneumatic Valve Positioner |
|
Control Technology |
Current-to-Pressure Conversion |
|
Electrical Input |
4–20 mA DC |
|
Communication Protocol |
Analogue, No HART |
|
Actuator Configuration |
Double Acting |
|
Pneumatic Spool |
High Performance, HP |
|
Pneumatic Connections |
1/4 Inch NPT |
|
Electrical Cable Entry |
1/2 Inch NPT |
|
Spindle Configuration |
Code 39 |
|
Cam Configuration |
K01 |
|
Position Indicator |
90° Direct-Acting Arrow Indicator |
|
Housing Material |
Die-Cast Aluminium |
|
Surface Treatment |
Epoxy Coating |
|
Supply Pressure Range |
1.4–10 Bar |
|
Operating Temperature |
−20°C to +85°C |
|
Input Impedance |
170–260 Ω at 20°C |
|
Linearity |
Less Than 1% of Full Scale |
|
Hysteresis |
Less Than 0.75% of Full Scale |
|
Repeatability |
Less Than 0.5% of Full Scale |
|
Deadband |
Less Than 0.15% |
|
Enclosure Protection |
IP66 / NEMA 4 |
|
Approximate Weight |
1.5 kg |
|
Calibration |
Adjustable Zero and Span |
|
Operating Medium |
Clean, Dry Instrument Air |
|
Condition |
New |
|
Warranty |
1 Year |
Key Features
Standard 4–20 mA analogue electropneumatic control
Double-acting pneumatic output for compatible actuators
High-performance spool valve for responsive positioning
Spindle configuration 39 with K01 cam
90-degree direct-acting visual position indicator
Durable die-cast aluminium housing with epoxy coating
Standard 1/4-inch NPT pneumatic connections
1/2-inch NPT electrical cable entry
Adjustable zero and span for simplified calibration
IP66/NEMA 4 enclosure protection
Built-in gauge ports for pneumatic pressure monitoring
Modular construction supporting compatible PMV accessories
Typical Applications
Industrial pneumatic control valve positioning
Oil and gas production and processing facilities
Chemical and petrochemical manufacturing plants
Petroleum refining installations
Power generation and utility systems
Water and wastewater treatment facilities
Industrial manufacturing automation
Rotary ball and butterfly valve control
Double-acting pneumatic actuator systems
Industrial flow and pressure regulation
