HLVP6 Kamoer Micro Diaphragm Vacuum Pump, 12–24V 5–8W 10L/min
The HLVP6 Kamoer micro diaphragm vacuum pump is a compact, electrically driven pump designed for air sampling, gas detection, and small-scale vacuum applications.
- 6 – 10 L/min Flow Rate
- 5 – 8 W Power Rating
Need help applying this product? Our engineers can help select the right equipment and design a system around your requirements. Request a quote or discuss your application with us.
Need help choosing? Send us the part number or your operating data — talk to an engineer or see full specifications.
- Fast dispatchAustralia & worldwide
- Technical supportTalk to an engineer
- 12 MonthsWarranty
Product Overview
The HLVP6 Kamoer micro diaphragm vacuum pump is a compact, electrically driven pump designed for air sampling, gas detection, and small-scale vacuum applications. Available in 12V and 24V configurations, it delivers efficient airflow with low power consumption.
With a maximum flow rate up to 10 L/min and options for brushed or brushless motors, this pump is ideal for portable systems, monitoring devices, and precision equipment.
Technical Specifications
| Specification | Value |
|---|---|
| Product Name | Micro Diaphragm Vacuum Pump |
| Model | HLVP6 |
| Brand | Kamoer |
| Pump Type | Diaphragm Pump |
| Structure | Micro Pump |
| Pressure | Vacuum Pressure |
| Max Continuous Pressure | Designed for micro vacuum systems |
| Flow Rate | 6 – 10 L/min |
| Speed Range | Motor dependent |
| Motor Type | Brushed / Brushless DC Motor |
| Power Source | Electric |
| Power Rating | 5 – 8 W |
| Voltage | 12V / 24V DC |
| Pump Body Material | Engineering Plastic |
| Connector Size | Micro fittings |
| Dimensions | 170 × 130 × 110 mm |
| Motor Options | Normal (N) / Enhanced (P) |
| Certification | CE / RoHS |
| Application Scope | Gas detection / Air sampling |
| MOQ | 1 PCS |
| Dimensions | Model dependent |
| Warranty | 12 Months |
Key Features
- Compact micro diaphragm pump design
- Available in 12V and 24V DC options
- Flow rate up to 10 L/min
- Low power consumption (5–8 W)
- Optional brushed or brushless motor
- Suitable for precision air and gas applications
Typical Applications
- Gas detection systems
- VOC monitoring equipment
- Air sampling stations
- Oil mist purification systems
- Food and beverage processing
- Household and portable devices
Shipping & Support
- Fast dispatch - Australia & World wide shipping
- Technical assistance available
- 12-month warranty
