IPVP6-125 Hydraulic Internal Gear Pump High Pressure
The IPVP6-125 hydraulic internal gear pump is a high-pressure pump engineered for industrial hydraulic systems requiring smooth, low-noise, and efficient fluid transfer.
- 125 cc/rev (Model Dependent) Displacement
- Up to 315 bar Max Continuous Pressure
- Configuration Dependent Rotation
Need help applying this product? Our engineers can help select the right equipment and design a system around your requirements. Request a quote or discuss your application with us.
Need help choosing? Send us the part number or your operating data — talk to an engineer or see full specifications.
- Fast dispatchAustralia & worldwide
- Technical supportTalk to an engineer
- 12 MonthsWarranty
Product Overview
The IPVP6-125 hydraulic internal gear pump is a high-pressure pump engineered for industrial hydraulic systems requiring smooth, low-noise, and efficient fluid transfer. Part of the IPV and IPVP series, including IPV3, IPV4, IPV5, IPVP5, IPVP6, IPVP7, and IPVAP5 models, this pump delivers stable flow output and reliable pressure performance under continuous-duty operation.
Designed with precision internal gearing and a robust housing structure, the IPVP6-125 provides excellent volumetric efficiency and reduced pulsation compared to conventional gear pumps. It is widely used in hydraulic power units, machine tools, and industrial automation systems where consistent hydraulic performance is essential.
Technical Specifications
| Specification | Value |
|---|---|
| Model | IPVP6-125 |
| Series | IPV / IPVP / IPVAP |
| Pump Type | Hydraulic Internal Gear Pump |
| Displacement | 125 cc/rev (Model Dependent) |
| Pressure Rating | High Pressure Configuration |
| Rotation | Configuration Dependent |
| Mounting Type | Flange Mount |
| Shaft Type | Splined or Keyed Shaft (Model Dependent) |
| Max Continuous Pressure | Up to 315 bar |
| Peak Pressure | Up to 350 bar |
| Housing Material | High-Strength Cast Iron |
| Application | Industrial Hydraulic Systems |
| Condition | New |
| Warranty | 12 Months |
Key Features
-
High-pressure hydraulic internal gear pump design
-
Smooth and low-noise operation
-
Reduced flow pulsation
-
High volumetric efficiency
-
Durable cast iron construction
-
Suitable for continuous industrial operation
Typical Applications
-
Hydraulic power packs
-
Machine tools
-
Industrial automation systems
-
Injection molding machines
-
Metal processing equipment
-
General industrial hydraulic circuits
