Magnetic Gear Pump, 0.32mL/rev, High Pressure
The Magnetic Gear Pump is designed for precision metering of cosmetic creams and viscous liquids. With a displacement of 0.32mL per revolution, it provides accurate dosing for small-volume applications.
Need help applying this product? Our engineers can help select the right equipment and design a system around your requirements. Request a quote or discuss your application with us.
Need help choosing? Send us the part number or your operating data — talk to an engineer or see full specifications.
- Fast dispatchAustralia & worldwide
- Technical supportTalk to an engineer
Product Overview
The Magnetic Gear Pump is designed for precision metering of cosmetic creams and viscous liquids. With a displacement of 0.32mL per revolution, it provides accurate dosing for small-volume applications.
Its magnetic drive mechanism ensures leak-free operation and consistent performance.
Technical Specifications
| Specification | Value |
|---|---|
| Pump Type | Magnetic Gear Pump |
| Displacement | 0.32 mL/rev |
| Pressure Type | High Pressure |
| Drive Type | Magnetic Coupling |
| Application | Cosmetic Cream Metering |
| Operation | Motor Driven |
| Installation | Compact Mount |
| Condition | New |
Key Features
-
Precision micro dosing
-
Magnetic drive sealing system
-
Suitable for viscous media
-
High-pressure capability
-
Stable flow control
-
Compact construction
Typical Applications
-
Cosmetic manufacturing
-
Pharmaceutical dosing
-
Laboratory testing
-
Precision dispensing
-
Industrial metering
Shipping & Support
-
Fast dispatch
-
Australia & world-wide shipping
-
Technical assistance available
-
Warranty available
