Rexroth A10VSO71 Axial Piston Hydraulic Pump, Variable Displacement
The Rexroth A10VSO71 is a high-performance variable displacement axial piston pump engineered for open circuit hydraulic systems operating under medium to high pressure conditions.
- 71 cc/rev Displacement
- Up to 280 bar Max Continuous Pressure
- Up to 3000 RPM (Application Dependent) Speed Range
Need help applying this product? Our engineers can help select the right equipment and design a system around your requirements. Request a quote or discuss your application with us.
Need help choosing? Send us the part number or your operating data — talk to an engineer or see full specifications.
- Fast dispatchAustralia & worldwide
- Technical supportTalk to an engineer
- 12 MonthsWarranty
Product Overview
The Rexroth A10VSO71 is a high-performance variable displacement axial piston pump engineered for open circuit hydraulic systems operating under medium to high pressure conditions. With a displacement of 71cc per revolution, it delivers precise and responsive flow control for demanding industrial and mobile applications.
Designed with a robust swashplate mechanism, the A10VSO series provides excellent volumetric efficiency, stable output performance, and reduced energy loss. Its heavy-duty cast iron housing and precision internal components ensure long service life and dependable operation in continuous-duty environments.
Technical Specifications
| Specification | Value |
|---|---|
| Model | A10VSO71 |
| Series | A10VSO |
| Pump Type | Axial Piston Pump (Variable Displacement) |
| Circuit Type | Open Circuit |
| Displacement | 71 cc/rev |
| Control Type | Hydraulic / Pressure / Load Sensing (Model Dependent) |
| Rotation | Right or Left (Configuration Dependent) |
| Mounting Type | Flange Mount |
| Shaft Type | Splined or Keyed (Configuration Dependent) |
| Max Continuous Pressure | Up to 280 bar |
| Peak Pressure | Up to 350 bar |
| Speed Range | Up to 3000 RPM (Application Dependent) |
| Housing Material | High-Strength Cast Iron |
| Condition | New |
| Warranty | 12 Months |
Key Features
-
Variable displacement for accurate flow control
-
High-pressure swashplate design
-
High volumetric efficiency
-
Low noise and smooth operation
-
Durable cast iron construction
-
Wide range of control configurations
-
Suitable for continuous-duty systems
Typical Applications
-
Construction machinery
-
Excavators and loaders
-
Agricultural equipment
-
Industrial hydraulic power units
-
Mining equipment
-
Material handling systems
Shipping & Support
-
Fast dispatch - Australia & World wide shipping
-
Technical assistance available
-
12-month warranty
