Rexroth A11VO40 Axial Piston Hydraulic Pump, Variable Displacement
The Rexroth A11VO40 is a high-pressure variable displacement axial piston pump designed for open circuit hydraulic systems in demanding mobile machinery applications.
- 40 cc/rev (95, 145, 190, 260 cc options available) Displacement
- Up to 350 bar Max Continuous Pressure
- Configuration Dependent Rotation
Need help applying this product? Our engineers can help select the right equipment and design a system around your requirements. Request a quote or discuss your application with us.
Need help choosing? Send us the part number or your operating data — talk to an engineer or see full specifications.
- Fast dispatchAustralia & worldwide
- Technical supportTalk to an engineer
- 12 MonthsWarranty
Product Overview
The Rexroth A11VO40 is a high-pressure variable displacement axial piston pump designed for open circuit hydraulic systems in demanding mobile machinery applications. Engineered for excavators and heavy equipment, the A11VO series delivers reliable flow control, high efficiency, and stable pressure performance under continuous-duty conditions.
Built with a rugged swashplate design and precision internal components, this pump ensures optimal power transmission and reduced energy loss. The A11VO range is widely used as a main pump in construction and earthmoving equipment where consistent hydraulic output is critical.
Technical Specifications
| Specification | Value |
|---|---|
| Model | A11VO40 (Other sizes available) |
| Series | A11VO |
| Pump Type | Axial Piston Pump (Variable Displacement) |
| Circuit Type | Open Circuit |
| Displacement | 40 cc/rev (95, 145, 190, 260 cc options available) |
| Control Type | Pressure / Load Sensing (Configuration Dependent) |
| Rotation | Configuration Dependent |
| Mounting Type | Flange Mount |
| Shaft Type | Splined Shaft |
| Max Continuous Pressure | Up to 350 bar |
| Peak Pressure | Up to 400 bar |
| Housing Material | High-Strength Cast Iron |
| Application | Excavator Main Pump |
| Condition | New |
| Warranty | 12 Months |
Key Features
-
High-pressure axial piston design
-
Variable displacement for precise flow control
-
Suitable as main pump for excavators
-
High volumetric efficiency
-
Heavy-duty cast iron housing
-
Designed for demanding mobile equipment applications
Typical Applications
-
Excavators
-
Earthmoving machinery
-
Construction equipment
-
Mining machinery
-
Heavy-duty hydraulic systems
-
Industrial mobile equipment
Shipping & Support
-
Fast dispatch - Australia & World wide shipping
-
Technical assistance available
-
12-month warranty
