Valmet Neles ND9103HNT ND9000 Intelligent Digital Valve Positioner
The Valmet Neles ND9103HNT Intelligent Digital Valve Positioner is designed for precise positioning and automated control of pneumatic valve actuators in industrial process systems.
- Single Acting and Double Acting Actuator Configuration
- 1.4–8 Bar Supply Pressure
Need help applying this product? Our engineers can help select the right equipment and design a system around your requirements. Request a quote or discuss your application with us.
Need help choosing? Send us the part number or your operating data — talk to an engineer or see full specifications.
- Fast dispatchAustralia & worldwide
- Technical supportTalk to an engineer
- 1 Year Warranty
Product Overview
The Valmet Neles ND9103HNT Intelligent Digital Valve Positioner is designed for precise positioning and automated control of pneumatic valve actuators in industrial process systems. Manufactured by Valmet under the Neles brand, this ND9000 series positioner uses a 4–20 mA electrical control signal with HART communication to regulate pneumatic output pressure and maintain accurate valve positioning. Its intelligent control technology supports stable flow regulation, responsive actuator operation, and reliable industrial automation.
The ND9103HNT features a medium-capacity pneumatic spool valve for actuators with stroke volumes of 1–3 litres, an integrated two-wire analogue position transmitter, automatic calibration, and advanced valve diagnostics. Its standard aluminium enclosure provides IP66/NEMA 4X protection, while compatibility with single-acting and double-acting actuators supports installation on suitable linear and rotary control valves. The positioner is ideal for oil and gas, chemical processing, power generation, water treatment, and industrial manufacturing applications.
Technical Specifications
|
Specification |
Value |
|---|---|
|
Product Name |
Intelligent Digital Valve Positioner |
|
Manufacturer / Brand |
Valmet / Neles |
|
Model Number |
ND9103HNT |
|
Product Series |
ND9000 |
|
Product Type |
Intelligent Electropneumatic Valve Positioner |
|
Electrical Input |
4–20 mA DC |
|
Communication Protocol |
HART |
|
Position Feedback Output |
4–20 mA, Two-Wire Passive Transmitter |
|
Actuator Configuration |
Single Acting and Double Acting |
|
Actuator Compatibility |
Linear and Rotary Pneumatic Actuators |
|
Pneumatic Spool Capacity |
Medium, Code 03 |
|
Recommended Actuator Stroke Volume |
1–3 Litres |
|
Supply Pressure |
1.4–8 Bar |
|
Pneumatic Connections |
G 1/4 |
|
Electrical Cable Entry |
M20 × 1.5 |
|
Housing Material |
Aluminium Alloy |
|
Enclosure Protection |
IP66 / NEMA 4X |
|
Explosion Protection |
None, N Configuration |
|
Operating Temperature |
−40°C to +85°C |
|
Calibration |
Automatic and Manual |
|
Position Measurement |
Contactless Electronic Position Sensing |
|
Diagnostics |
Advanced Valve and Device Diagnostics |
|
Mounting Standard |
VDI/VDE 3845 |
|
Operating Medium |
Clean, Dry Instrument Air |
|
Related Models |
ND9106HNT, ND9102HNT |
|
Condition |
New |
|
Warranty |
1 Year |
Key Features
Intelligent digital valve positioning with HART communication
Standard 4–20 mA electrical input for industrial control systems
Integrated 4–20 mA analogue position feedback transmitter
Medium-capacity pneumatic spool for 1–3 litre actuators
Compatible with single-acting and double-acting pneumatic actuators
Automatic calibration for simplified commissioning
Advanced diagnostics for valve performance monitoring
Contactless position sensing for accurate actuator feedback
Durable aluminium housing with IP66/NEMA 4X protection
Supports linear and rotary pneumatic valve applications
Typical Applications
Industrial pneumatic control valve positioning
Oil and gas production and processing facilities
Chemical and petrochemical manufacturing plants
Petroleum refining installations
Power generation and utility systems
Water and wastewater treatment facilities
Pulp and paper processing plants
Industrial manufacturing automation
Linear globe and rotary valve control
HART-compatible process control systems
Shipping & Support
Fast dispatch – Australia & Worldwide Shipping
Technical assistance available
1-year warranty
