Flowserve 420-47W1D-11 Logix 420 Digital Valve Positioner with HART
The Flowserve 420-47W1D-11 Logix 420 Digital Valve Positioner is designed for precise positioning and automated control of pneumatic valve actuators in industrial process systems.
- Single Acting Actuator Configuration
- 1.5 Bar (22 psi) Minimum Supply Air Pressure
Need help applying this product? Our engineers can help select the right equipment and design a system around your requirements. Request a quote or discuss your application with us.
Need help choosing? Send us the part number or your operating data — talk to an engineer or see full specifications.
- Fast dispatchAustralia & worldwide
- Technical supportTalk to an engineer
- 1 YearWarranty
Product Overview
The Flowserve 420-47W1D-11 Logix 420 Digital Valve Positioner is designed for precise positioning and automated control of pneumatic valve actuators in industrial process systems. Manufactured by Flowserve, this intelligent electropneumatic positioner operates using a standard 4–20 mA electrical input signal with HART digital communication to regulate pneumatic output pressure and maintain accurate valve positioning. Its single-acting pneumatic configuration supports responsive actuator movement, stable flow regulation, and dependable operation in demanding industrial environments.
Part of the Flowserve Logix 420 series, the 420-47W1D-11 features microprocessor-based control, piezoelectric pneumatic technology, automatic calibration, and digital diagnostic capabilities. Its aluminium housing with a protective white coating, 316 stainless steel feedback shaft, integrated LCD display, and pressure gauge support reliable industrial operation and convenient monitoring. Designed for compatible linear and rotary pneumatic actuators, the positioner offers HART communication, adjustable control characteristics, and flexible mounting arrangements. Related models include the 420-47W1R-30 and 420-47-W1D-01, which feature different feedback shaft and instrument configurations.
Technical Specifications
|
Specification |
Value |
|---|---|
|
Product Name |
Digital Electropneumatic Valve Positioner |
|
Brand |
Flowserve |
|
Manufacturer |
Flowserve Corporation |
|
Model |
420-47W1D-11 |
|
Series |
Logix 420 |
|
Product Type |
Intelligent Digital Valve Positioner |
|
Control Technology |
Microprocessor-Based Electropneumatic |
|
Pneumatic Technology |
Piezoelectric |
|
Actuator Configuration |
Single Acting |
|
Actuator Compatibility |
Pneumatic Linear and Rotary Actuators |
|
Input Signal |
4–20 mA DC |
|
Communication Protocol |
HART 6, Configurable to HART 7 |
|
Operating Mode |
Two-Wire, Loop Powered |
|
Diagnostic Configuration |
Standard Diagnostics |
|
Minimum Supply Air Pressure |
1.5 Bar (22 psi) |
|
Maximum Supply Air Pressure |
6 Bar (87 psi) |
|
Pneumatic Output Pressure |
0–100% of Supply Pressure |
|
Housing Material |
Cast Aluminium |
|
Housing Finish |
White Powder Coating |
|
Static Seal Material |
Buna-N |
|
Dynamic Seal Material |
Fluorosilicone |
|
Pneumatic Connection |
1/4 Inch NPTF |
|
Electrical Conduit Connection |
1/2 Inch NPTF |
|
Feedback Shaft |
316 Stainless Steel, Valtek Standard |
|
Feedback Shaft Spring Bias |
Counterclockwise |
|
Pressure Gauge |
Nickel-Plated Gauge with Brass Internals |
|
Pressure Gauge Units |
psi and bar/kPa |
|
Display Type |
LCD with Window Cover |
|
Feedback Shaft Rotation |
15–90° |
|
Operating Temperature |
-52°C to +85°C |
|
Protection Rating |
IP66, Subject to Configuration |
|
Calibration |
Automatic Stroke Calibration |
|
Control Function |
Automatic Valve Position Regulation |
|
Configuration Interface |
Local Controls, HART and ValveSight DTM |
|
Working Medium |
Clean, Dry Instrument Air |
|
Related Models |
420-47W1R-30, 420-47-W1D-01 |
|
Application Scope |
Industrial Pneumatic Valve Control Systems |
|
Condition |
New |
|
Warranty |
1 Year |
Key Features
-
Intelligent digital valve positioning for accurate industrial pneumatic actuator control.
-
Single-acting pneumatic configuration for dependable operation with compatible control valve actuators.
-
Standard 4–20 mA electrical input signal for integration into industrial automation systems.
-
HART 6 communication with configurable HART 7 support for remote monitoring and instrument configuration.
-
Microprocessor-based control technology for precise and responsive valve positioning.
-
Piezoelectric pneumatic control mechanism for efficient instrument air regulation.
-
Automatic stroke calibration for simplified installation, setup, and commissioning.
-
Standard diagnostic functions for monitoring valve travel, instrument status, and operating performance.
-
Integrated LCD display with window cover for convenient local monitoring and configuration.
-
Nickel-plated pressure gauge with brass internals for pneumatic pressure monitoring.
-
Durable cast aluminium housing with protective white coating for industrial applications.
-
316 stainless steel feedback shaft with counterclockwise spring bias for compatible Valtek mounting arrangements.
-
Adjustable control response and automatic tuning capabilities for optimising actuator performance.
-
Maximum pneumatic supply pressure of 6 bar for suitable single-acting actuator applications.
-
Local status LEDs and configuration controls for convenient operation and troubleshooting.
-
Compatible with linear and rotary pneumatic valve actuators using appropriate mounting hardware.
-
Suitable for continuous industrial process automation and pneumatic control valve applications.
Typical Applications
-
Industrial process automation systems
-
Pneumatic control valve assemblies
-
Oil and gas production and processing facilities
-
Chemical and petrochemical plants
-
Power generation and utility systems
-
Water and wastewater treatment facilities
-
Industrial manufacturing machinery
-
Pneumatic linear actuator positioning
-
Rotary control valve automation
-
Industrial flow and pressure regulation systems
-
Distributed control systems with HART communication
-
Industrial process instrumentation
-
Automated fluid handling and production equipment
-
Control valve maintenance and replacement applications
