Vertical Axial High Pressure Pump, 10 L/min 180 bar
This vertical axial high pressure pump is designed for efficient and reliable performance in cleaning and wastewater systems.
- 10 L/min Flow Rate
- 180 Bar (18 MPa) Working Pressure
- 7 HP Horsepower
Need help applying this product? Our engineers can help select the right equipment and design a system around your requirements. Request a quote or discuss your application with us.
Need help choosing? Send us the part number or your operating data — talk to an engineer or see full specifications.
- Fast dispatchAustralia & worldwide
- Technical supportTalk to an engineer
- 1 YearWarranty
Product Overview
This vertical axial high pressure pump is designed for efficient and reliable performance in cleaning and wastewater systems. Built with a durable copper head and piston structure, it ensures consistent pressure output and long operational life under demanding conditions.
With a working pressure of 180 bar (18 MPa) and a flow rate of 10 L/min, this pump is suitable for high-pressure washing, fluid transfer, and wastewater applications. Its compact axial design allows for easy integration into various equipment setups.
Technical Specifications
| Specification | Value |
|---|---|
| Product Name | High Pressure Axial Pump |
| Pump Type | Axial Piston Pump |
| Structure | Piston Pump |
| Material | Copper Head |
| Flow Rate | 10 L/min |
| Working Pressure | 180 Bar (18 MPa) |
| Equivalent Pressure | ~2700 PSI |
| Rated Speed | 3400 RPM |
| Horsepower | 7 HP |
| Power Range | 6 – 7.5 HP |
| Motor Type | Gasoline / Diesel |
| Voltage | 220 V |
| Outlet Size | M22 |
| Power Source | Engine Driven |
| Condition | New |
| Customization Support | OEM, ODM, OBM, Software Reengineering |
| Medium | Water |
| Application Scope | Industrial |
| Warranty | 1 Year |
Key Features
- High-pressure performance up to 180 bar (~2700 PSI)
- Durable copper head for extended service life
- Compact vertical axial design for easy installation
- Stable piston structure for smooth operation
- Compatible with gasoline or diesel engines
- Reliable performance in continuous-duty applications
Typical Applications
- High-pressure cleaning systems
- Wastewater treatment equipment
- Agricultural spraying systems
- Industrial washing equipment
- Water transfer and pressure boosting
Shipping & Support
- Fast dispatch - Australia & World wide shipping
- Technical assistance available
- 12-month warranty
